COPYRIGHT
©
2001 CANON INC. 2000 2000 2000 2000 CANON iR8500/7200 REV.1 AUG. 2001
CHAPTER 6 TROUBLESHOOTING
6-36
Pickup motor
Pickup drive belt
Main drive belt
Main motor
Developing/waste toner drive belt
2.4.19 Attaching the Drive Belts
Be sure to attach the drive belts on the pulleys and the rollers as shown.
F06-204-23
