COPYRIGHT
©
2001 CANON INC. 2000 2000 2000 2000 CANON iR8500/7200 REV.1 AUG. 2001
CHAPTER 6 TROUBLESHOOTING
6-93
4 Troubleshooting Malfunctions
4.1 Troubleshooting Malfunctions
If you must remove and mount a sensor, pay attention to the orientation/po-
sition of the spring used to lock its detecting lever in place while doing so.
4.1.1 E000
Thermistor
1) Reset E000, and turn off and then on the power switch. Make the
following selections in service mode:
COPIER>DISPLAY>ANALOG. Is overheating noted for both
‘FIX-C’ and ‘FIX-E’?
YES: The thermistor is faulty; check the following:
• Thermistor for mounting condition
• Thermistor surface for dirt
• Connection
DC controller PCB
2) Turn offf the power switch, cooling the fixing upper roller suffi-
ciently, and turn on the power switch. Reset E000, and turn off and
then on the power switch. Make the following selections in service
mode: COPIER>I/O>DC-CON. Are bit 0 and bit 1 of IO-P12 ‘0’?
YES: Replace the DC controller PCB.
Heater (open circuit), AC driver PCB
3) Is the electrical continuity of each heater normal?
NO: Replace the heater.
YES: Check the wiring; if normal, replace the AC driver PCB.
To Next Page
