CHAPTER 4 INSTALLATION
4-65
COPYRIGHT
©
2001 CANON INC. 2000 2000 2000 2000 CANON iR8500/7200 REV.1 AUG. 2001
6 Installing the NE Controller-A1/NE Controller-B1/
Copy Data Controller-A1
6.1 Installing the NE Controller-A1/NE Controller-B1/Copy
Data Controller-A1
Here, the instructions are limited to installation to the copier. For how to
make various settings, checks to make, and points to note, see the Installa-
tion Procedure that comes with a specific controller.
No. Work Checks/remarks
1 Remove the 4 screws [1] that come with
the rear cover of the host machine, and
remove the face cover [2].
If you are installing a Copy
Data Controller-A1 to a
230V machine, go to step 4).
F04-601-01
[2]
[1]
[1]
To Next Page
