CHAPTER 2 NEW FUNCTIONS
2-15
COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
2.9.1 No
.
1 Mirror Base Assembly
a.
Remove the Scanning Lamp/Scanning Lamp Heater
1)
Remov
e the 2 screws [1], and detach the
right glass retainer [2].
2)
Shift the copyboard glass [3] to the
right to detach; then, detach the scan-
ning lamp cov
er [4].
F02-209-01
3)
Remov
e the 4 screws [1], and detach the
original lamp inside cov
er [2].
F02-209-02
[1]
[3]
[1]
[4]
[2]
[2]
[1]
[1]
