DescriptionField
Current cache size.Size
Current value for the inactive timeout in seconds.Inactive Timeout
Current value for the active timeout in seconds.Active Timeout
Current value for the update timeout in seconds.Update Timeout
The following example displays the status, statistics, and data for the flow monitor named FLOW-MONITOR-1:
Device# show flow monitor FLOW-MONITOR-1 cache
Cache type: Normal (Platform cache)
Cache size: Unknown
Current entries: 1
Flows added: 3
Flows aged: 2
- Active timeout ( 300 secs) 2
DATALINK MAC SOURCE ADDRESS INPUT: 0000.0000.1000
DATALINK MAC DESTINATION ADDRESS INPUT: 6400.F125.59E6
IPV6 SOURCE ADDRESS: 2001:DB8::1
IPV6 DESTINATION ADDRESS: 2001:DB8:1::1
TRNS SOURCE PORT: 1111
TRNS DESTINATION PORT: 2222
IP VERSION: 6
IP PROTOCOL: 6
IP TOS: 0x05
IP TTL: 11
tcp flags: 0x20
counter bytes long: 132059538
counter packets long: 1158417
This table describes the significant fields shown in the display.
Table 26: show flow monitor monitor-name cache Field Descriptions
DescriptionField
Flow monitor cache type. The value is always normal,
as it is the only supported cache type.
Cache type
Number of entries in the cache.Cache Size
Number of entries in the cache that are in use.Current entries
Flows added to the cache since the cache was created.Flows added
Flows expired from the cache since the cache was
created.
Flows aged
Current value for the active timeout in seconds.Active timeout
Current value for the inactive timeout in seconds.Inactive timeout
Command Reference, Cisco IOS XE Everest 16.5.1a (Catalyst 3650 Switches)
468
show flow monitor
