15 February 2006 COPY CONNECTOR KITS
1-131
Installation
Preparation
Before you begin the installation procedure:
• Measure the distance between the machines to be connected.
• Confirm that the printer/scanner option is installed on the machines.
Determine the number of cables and repeater hubs that are necessary based on
the distance measured between the machine.
DISTANCE
POWER REPEATER
HUBS REQUIRED
INTERFACE CABLES
REQUIRED
Up to 4.5 m (14.8 ft.) None 1
4.5 ~ 9.0 m (14.8 ~ 29.5 ft) 1 2
9.0 ~ 13.5 m (29.5 ~ 112.5 ft. 2 3
• Install the key labeled “Printer/Other Function + Scanner” (or its equivalent
symbol key-top for EU) on a machine with the printer/scanner option installed
• Install the key labeled “Other Function” (or its equivalent symbol key-top for EU)
on a machine without the printer/scanner option.
To Next Page
