DUPLEX UNIT
15 February 2006
3-88
3.10.4 DUPLEX
M
OTORS
Duplex Inverter M
otor
[A]:
Remove the cov
er (
x 3)
[B]:
Inverter
motor bracket (
x 3)
[C]:
Inverter motor (
harness x 1,
x 1,
x 2, timi
ng belt x 1)
B246R1038.WMF
B246R1039.WMF
[A]
[B]
[C]
316
318
