15 February 2006
DEVELOPMENT UNIT
3-53
Replacement
Adjustm
ent
3.7.7 DEVELOPMENT
MO
TOR
[A]: Fly
wheel
(
x 3
)
[B]:
W
aste toner pump tube (
x 1,
x 1)
[C]: Drive
rod
•
Lift the toner pump tube to disengage the dr
ive rod, pull out the r
od, and
push the rubber tube aside.
[D]:
Development motor bracket (
x 3,
x 1)
[E]:
Development motor (
x 4
)
B246R974.WMF
B246R975.WMF
[D]
[E]
[A]
[B]
[C]
281
283
