SERVICE PROGRAM MODE TABLES 15 February 2006
5-56
SP4xxx Scanner
4008* Scanner Sub Scan Magnification
Fine adjusts the magnification in the sub scan direction for scanning by changing
the speed of the scanner motor.
[–0.9~+0.9/0.1 %]
Setting a lower value reduces the speed of the motor and lengthens the image in
the sub scan direction (direction of paper feed).
Setting a higher value increases the speed of the motor speed and shortens the
image in the sub scan direction.
4010* Scanner Leading Edge Registration
Adjust the registration of the leading edge for scanning in the sub scan direction.
[–0.9~+0.9/0.1 %]
This setting ensures that the point where the original strikes the registration roller
matches the point where the F-GATE signal will trigger the start of scanning in the
main scan direction.
Setting a larger value shifts the image away from the leading edge, and a smaller
value shifts the image toward the leading edge.
4011* Scanner Side-to-Side Registration
Adjusts the side-to-side registration for scanning in the main scan direction across
the page.
[–0.3~+0.3/0.1 %]
Setting a negative value shifts the image toward the left edge, and setting a
positive value shifts the image toward the right edge.
4012* Scanner Erase Margin
These settings adjust the margins (erase margins) of the scanned area on the
sheet. The leading, trailing, right, and left margins can be set independently.
001 Leading Edge
002 Trailing Edge
003 Right
004 Left
[0~0.9/0.1 mm]
4013 Scanner Free Run
Switches on/off a scanner free run. The scanning area is A3.
Press “On” or “Off”.
001 Scanner Free Run: Lamp On Performs a scanner free run with the
exposure lamp on.
002 Scanner Free Run: Lamp Off Performs a scanner free run with the
exposure lamp off.
