15 February 2006 SERVICE PROGRAM MODE TABLES
5-119
Service
Tables
SP6xxx Peripherals
6006* ADF Registration Adjustment
001 ADF Horizontal Registration (Front)
Adjusts the side-to-side registration for the front in ADF mode.
[–3~+3/0.1 mm]
002 ADF Horizontal Registration (Back)
Adjusts the side-to-side registration for the back in ADF mode.
[–3~+3/0.1 mm]
003 ADF Vertical Registration (Front)
Adjusts the vertical registration for the front in ADF mode.
[–30 ~+30/1 mm]
-30 = -5.1 mm
+30 = +5.1 mm
004 ADF Vertical Registration (Back)
Adjusts the vertical registration for the back in ADF mode.
[–30 ~+30/1 mm]
-30 = -5.1 mm
+30 = +5.1 mm
005 ADF Buckle Adjustment 1
Adjusts the roller timing at the skew correction sensor/entrance roller. A higher
setting causes more buckling.
[–12.0~+12/0.25 mm]
-12 = -3.0 mm
+12 = +3.0 mm
006 ADF Buckle Adjustment 2
Adjusts the roller timing at the interval sensor/scanning roller. A higher setting
causes more buckling.
[–8.0~+8/0.25 mm]
-8 = -2 mm
+8 = +2 mm
007 ADF Trailing Edge Erase Margin (Front)
These settings adjust the erase margin for the trailing edges for the front.
[–20~+20/0.5 mm]
-20 = -10 mm
+20 = +10 mm
008 ADF Trailing Edge Erase Margin (Back)
These settings adjust the erase margin for the trailing edges for the back.
[–20~+20/0.5 mm]
-20 = -10 mm
+20 = +10 mm
