MFP OPTIONS: B064 SERIES 15 February 2006
1-148
UP Mode Settings for Wireless LAN
Enter the UP mode and follow the procedure below to perform the initial interface
settings for IEEE 802.11. These settings take effect every time the machine is
powered on.
NOTE: The wireless LAN cannot be used if Ethernet is being used.
1. Press the User Tools/Counter key.
2. On the touch panel, press System Settings.
NOTE: The Network I/F (default: Ethernet) must be set for either Ethernet or
wireless LAN.
3. Select Interface Settings → Network (tab) → Network I/F Settting
4. Select either “Ethernet” or “IEEE 802.11b”.
5. Press IEEE 802.11b. Only the wireless LAN options are displayed.
6. Transmission Mode. Select either “Ad Hoc Mode” or “Infrastructure Mode”.
7. SSID Setting. Enter the SSID setting. (The setting is case sensitive.)
8. Channel. This setting is required when Ad Hoc Mode is selected.
Range: 1 ~ 14 (default: 11)
NOTE: The allowed range for the channel settings may vary for different
countries.
Network Parallel Interface IEEE 1394
IEEE 802.1b
Transmission Speed
SSID Setting
Channel
WEP (Privacy) Setting
802.11 Ad Hoc Mode
ASSID
11
Disabled
Select the desired settings.
System Intialization Settings End
Bandwidth Status
NextPrevious
1/2
B064I997.WMF
To Next Page
