3000-SHEET FINISHERS (B468/B469/B674) 15 February 2006
1-40
Selecting the Staple Supply Name
Enter the SP mode and execute the following information.
Supply Name Setting These names appear when the user presses the Inquiry
button on the initial User Tools screen.
005 Staple Std Enter the name of the staples in use for normal stapling
(not booklet stapling). This setting should be done for the
B468, B469, and B674.
5841*
006 Staple Bind Enter the name of the staples in use for booklet stapling
(saddle-stitching). This setting is required only for the
B468 and B674
Enabling Booklet Binding
To enable booklet binding, you must select the ‘center stapling’ position.
1. Press the User Tools key.
2. Touch “Copier/Document Server Features”.
3. Touch the “Input/Output” tab, then access “Select Stapling Position”.
4. Touch any “Stapling Position” button and touch the center stapling symbol.
5. Exit the User Tools mode. Specify the number of copies, touch the center
stapling symbol on the operation panel, then start the print job.
These SP adjustments are available but not required at installation.
SP6902 Fold Position
Adjustment
Use this SP to fine adjust the fold and staple positions if they
are not aligned correctly. See “5. Service Tables”.
SP6120 Staple Jogger
Adjustment
Allows fine adjustment of the staple unit jogger fences for
different paper sizes, if required. See “5. Service Tables”.
