15 February 2006 PM TABLES
2-5
Preventive
Maintenance
2.1.2 ADF
The PM interval is for the number of originals that have been fed.
EM 80K 160K 240K Expected K Note
Pick-up Roller C R R R
Separation Roller C R R R
Paper Feed Belt C R R R
Water or alcohol, belt cleaner
to clean paper feed belt.
Replace these items together.
CIS Glass C C C Dry cloth
White Guide Plate C C C Dry cloth
Sensors C C C C Blower brush.
Platen Cover Sheet C C C C Water or alcohol
Drive Gears L L L Grease G501.
Transport Rollers C C C
Entrance Roller C C C
White Platen Roller C C C
Pre-Scanning Roller C C C
Scanning Roller C C C
Exit Roller C C C
Water or alcohol
2.1.3 OPTIONAL PERIPHERAL DEVICES
LCT (Large Capacity Tray) B473
ROLLRES
EM 300K 450K 1000K Expected K Note
Pick-up Roller R
Feed Roller R
Separation Roller R
See
NOTE below this table.
NOTE: Replace pick-up, feed and separation rollers as a set. If the copier is a
machine of the B064 Series, check the counter value for each paper tray
station with SP7204 (Copy Counter – Paper Trays). If the value has
reached 300K, replace the rollers. After replacing the rollers, reset the
counter with SP7816 (Copy Counter Reset).
Cover Interposer Tray B470
The PM interval is for the number of sheets that have been fed.
EM 60K 120K 180K Note
Feed Belt R R R
Pick-up Roller R R R
Separation Roller
R R R
Replace as a set.
Driver Rollers C C C
Idle Rollers C C C
Discharge Brush C C C
Damp clean cloth.
Bushings L Lubricate with silicone oil if noisy.
Sensors C C C Blower brush.
Feed Drive Gear L Lubricate with silicone oil if noisy.
To Next Page
