ADF
15 February 2006
3-142
3.13.4 SEPA
RA
TION
ROLLER
Open the feed cover.
Feed unit (
☛
3.11.8)
[A]:
Separation rol
ler cover
•
Use the tip of a screwdri
ver to push up the cover.
[B]: C-Clamp
(
x 1)
[C]: Separation
r
oller
[D]:
Torque limiter clutch
B140R870.WMF
[A]
[B]
[C]
[D]
370
372
