INPUT/OUTPUT CHECK 15 February 2006
5-204
5.6.9 FINISHER 2 INPUT CHECK: 6122
6122 Finisher Input Check Finisher 2
These are the input checks for the 3000-Sheet Finisher B706.
001 Entrance Sensor 021 Proof Full Sensor
002 Proof Exit Sensor 022 Stapler Moving HP Sensor
003 Shift Exit Sensor 023 Staple Waste Hopper Sensor
004 Staple Exit Sensor 024 Pre-Stack Tray HP Sensor
005 Tray Lower Sensor 025 Hold HP Sensor
006 Tray Near Lower Sensor 026 Exit Guide HP Sensor
007 Stack Feed Out HP Sensor 027 Stapler Reverse Sensor
008 Jogger HP Sensor 028 Stapler Sensor
009 Shift HP Sensor 029 Front Hold HP Sensor
010 Stapler Moving HP Sensor 030 Rear Hold HP Sensor
011 Staple HP Sensor 031 Knock Hold HP Sensor
012 Staple Cartridge Sensor 032 Reverse Drive HP Sensor
013 Staple Tray Paper Sensor 033 Paper Sensor
014 Door Sensor 034 Tray Lower Sensor
015 Punch Unit Sensor 035 Punch HP2 Sensor
016 Punch HP Sensor 036 Shift Jogger Sensor
017 Punch Chad Full Sensor 037 Shift Jogger HP Sensor
018 Paper Detection Sensor: Staple 038 Shift Jogger Release HP Sensor
019 Paper Detection Sensor: Shift 039 Front Door Safety Switch
020 Staple Cartridge Set Sensor
