SPECIFICATIONS 15 February 2006
Spec-10
3.5 3000-SHEET FINISHER WITH SADDLE-STITCH AND 50-SHEET
STAPLER (B674)
General
Rated Voltage of Output
Connector
Max. DC 24 V
Dimensions (W x D x H) 700 x 620 x 960 mm (27.6" x 24.4" x 37.8")
Weight Approx. 65 kg (143 lb.) (with punch unit)
Power Consumption 72 W (3 A/24 V)
Power Supply DC 24 V
Upper Tray
Unstapled 500 sheets (A4, A5 LEF, B5, 81/2" x 11")
250 sheets (A3 SEF, B4 SEF, 12" x 18", 11" x 17" SEF)
100 sheets (A5 SEF, B6 SEF, 5
1/2" x 81/2")
Max docs. Total sheets Size
50 docs. 500 sheets A4 LEF, 81/2" x 11" LEF
Tray Capacity
(80 g/m
2
)
Stapled
25 docs. 250 sheets A3, A4 SEF, B4, B5, 12" x
18", 11" x 17", 8
1/2" x 11"
Paper Size A3 ~ A5, A6 SEF, B6 SEF, 12" x 18", 11" x 17" ~ 51/2" x 81/2"
Paper Weight
52 g/m
2
~ 216 g/m
2
(14 ~ 58 lb)
Mixed Sizes A3 and A4 LEF, B4 and B5 LEF, 11" x 17" and 81/2" x 11" LEF
(Max: 16 docs, Max sheets: 30 sheets or less)
Note: Z-folded paper cannot be output to the upper tray.
