15 February 2006
IMAGE TRANSFER AND PAPER SEPARAT
ION
6-87
Detailed
Descriptions
6.10.8 ANTI-CONDENS
ATION
HE
ATER
The anti-
condensatio
n heater [A] i
s directly be
low the trans
fer belt driv
e roller.
This anti-co
ndensation hea
ter turns on auto
matically at the
following ti
mes:
•
When the main power sw
itch is turned off
•
W
hen the m
ach
ine e
nter
s au
to of
f mo
de
B246D944.
W
MF
[A]
782
