15 February 2006
PAPER FEED
3-107
Replacement
Adjustm
ent
[A]:
Guide plate (
x 1)
•
1st feed unit only.
[B]:
Feed unit (
x 1,
x 3
)
•
Insert your hand from the ri
ght and pull the feed unit forward.
NOTE:
To avoid hitti
ng the unit on the sides of the machine, remove it
carefully and slow
ly.
B246R1070.WMF
B246R1078.WMF
[A]
[B]
335
337
