SERVICE PROGRAM MODE TABLES 15 February 2006
5-30
5.5.2 COPIER SERVICE TABLE
SP1xxx Feed
1001* Leading Edge Registration
Adjusts the printing leading edge registration using the trimming area pattern
(SP2902-003, No.18).
[–9~+9/0.1mm]
Specification: 3±2mm
1002* Side-to-Side Registration
Adjusts printing side-to-side registration for each feed station, using test pattern
(SP2902-003, No.18).
These SP’s should be adjusted after replacing the laser synchronization detector or
the laser optical unit.
001 Tray-1 [–9~+9/0.1 mm]
002 Tray-2
003 Tray-3
004 Tray-4 (Japan Only)
005 By-pass Tray
006 LCT
007 Duplex Tray
1003 Registration Buckle Adjustment
Adjusts the registration motor timing. This timing determines the amount of paper
buckle at registration. (A higher setting causes more buckling.)
[–9~+9/1 mm]
001* Tray LCT
002 Duplex Tray
003* By-pass Tray
1007 By-pass Feed Paper Size Display
Use this SP to confirm the size of the paper detected in the by-pass tray if paper is
skewing during feeding.
1008* Duplex Fence Adjustment
Adjusts the distance between front and rear fences. A smaller value shortens the
distance. If the fences are too far apart, skewing may occur in the duplex tray. If
the fences are too close, the paper may be creased in the duplex unit.
[–5~+5/0.1 mm]
