15 February 2006 FUSING UNIT

3-73

Replacement

Adjustment

B140 Series: Fusing Lamps

Fusing unit (☛ 3.9.1)

[A]: Rear bracket (x 2 at ➀, x 1 at ➁)

[B]: White connector ( x 1)

[C]: Lock bracket ( x 1)

[D]: Rear terminal connector bracket ( x 1 at

➂ under metal clamp,  x 1 at ➃)

[E]: Connector ( x 1,  x 1)

[F]: Blue, green connectors

[G]: Rear fusing lamp holder ( x 1)

B246R1005.WMF

[A]

[C][D]

[E]

[F]

B140 Series Rear

➀

➁➂

➃

[B]

[G]

[F]
