15 February 2006
PCBS AND HDD
3-129
Replacement
Adjustm
ent
3.12.5
PSU, PFC BOARDS
B064 Series
Rear lower cover (
☛
3.3.5)
[A]:
Harness clamps (
x 3)
[B]: PSU
(
x 6,
x 13)
•
The PSU consists of two PCB’s.
[C]: PFC
(
x 4,
x 14)
B140 Series PSU
Rear cov
ers (
☛
3.3.5)
Controller
box cover (
x 12)
[A]: PSU
(
x 5
,
x 7
)
B246R862.WMF
B246R703.WMF
[A]
[C]
[B]
[A]
357
359
