15 February 2006 IMAGE TRANSFER AND PAPER SEPARATION
6-83
Detailed
Descriptions
6.10.4 TRANSFER CURRENT SETTINGS
Here is a list of the default current settings for each paper feed station.
SP No. Station/Mode Transfer Current (Initial Value)
SP2301-001 Trays 1, 2, 3: Front Side
80 µA
SP2301-002 Trays 1, 2, 3: Back Side
80 µA
SP2301-003 Bypass: Front Side
75 µA
SP2301-004 Postcard: Front Side
165 µA
SP2301-005 Paper Interval
15 µA
SP2301-006 Tab Paper
75 µA
SP2301-007 Thick Paper: Front Side
120 µA
SP2301-008 OHP: Front Side
75 µA
SP2301-009 Tracing Paper: Front Side
120 µA
SP2301-010 Image Leading Edge
65 µA
SP2301-011 Image Trailing Edge
65 µA
NOTE: 1) For postcards, use the by-pass tray and set the side fences for A6
width.
2) The charge for cleaning is applied even during the interval between
sheets of copy paper.
3) At the following times, the transfer roller output changes to 2.6 kV, and
the cleaning roller output is fixed at 1.0 kV:
• When the job ends
• Whenever the drum motor is turning, except during copying and during
process control
