FUSING UNIT
15 February 2006
3-80
3.9.10 STRIPPER
PA
WLS
B064 Series
Remove the fusing uni
t (
☛
3.9.1)
[A]:
Top cover (
x 1)
[B]: Bracket
(
x 1, spri
ng x 1)
[C]:
Inner cover (
x 2
)
[D]:
Stripper paw
l (
x 1, spring
x 3)
B246R1015.WMF
B246R1016.WMF
[C]
[D]
[A]
[B]
308
310
