DRUM UNIT
15 February 2006
3-46
3.6.17 OZONE
FILTERS
[A]:
Filter cover (
x 1
)
•
The f
ilter cov
er is on the back of
the machine.
[B]:
Ozone filter
(top)
[C]:
Ozone filter (
bottom)
3.6.18
OPTI
CS DUST FILTER
[A]: Filter
cover
[B]:
Optics dust filter
3.6.19
I
NTERNA
L DUST FI
LTER
1.
Open the front door.
2.
Pull out the internal
dust f
ilter [A].
B246R961.WMF
B246R962.WMF
B246R963.WMF
[A]
[C]
[A]
[B]
[A]
[B]
274
276
