15 February 2006 INPUT/OUTPUT CHECK
5-203
Service
Tables
5.6.8 FINISHER 1 OUTPUT CHECK: 6124
6124 Finisher Output Check: Finisher 1
These are the output checks for the 2000-Sheet/3000-Sheet Finishers B700/B701.
001 Entrance Motor 017 Knock (Positioning Roller) Solenoid
002 Upper Feed Motor 018 Trailing Edge Hold Sensor
003 Lower Feed Motor 019 Saddle-Stitch Hold Sensor
004 Exit Motor 020 Stack Junction Gate Motor
005 Knock (Positioning) Roller Motor 021 Trailing Edge Fence Main Motor
006 Shift Motor 022 Saddle-Stitch Stapler Motor: Front
007 Exit Guide Plate Motor 023 Saddle-Stitch Stapler Motor: Rear
008 Tray Lift Motor 024 Folder Plate Motor
009 Oscillating Back Roller Motor 025 Folder Roller Motor
010 Jogger Motor 026 Drive Roller Oscillating (Clamp) Motor
011 Stack Feed Out Motor 027 Punch Motor
012 Stapler Moving Motor 028 Punch Moving Motor
013 Staple Skew (Rotation) Motor 029 Punch Registration Detection Motor
014 End Stapler Motor 030 Exit Jogger Motor: Front
015 Upper Junction Gate Solenoid 031 Exit Jogger Motor: Rear
016 Lower Junction Gate Solenoid 032 Exit Jogger Release Motor
