15 February 2006 PAPER FEED
3-113
Replacement
Adjustment
3.11.14 REGISTRATION SENSOR
[A]: Inner cover ( x 4)
Development unit (☛ 3.6.1)
Charge corona unit (☛ 3.6.2)
OPC drum unit (☛ 3.6.5)
[B]: Paper dust removal unit ( x 1,  x 1)
[C]: Registration sensor
B246R1094.WMF
B246R1095.WMF
[A]
[B]
[C]
