15 February 2006 B140/B246 SERIES SERVICE MODE
4-77
Trouble-
shooting
Finisher B469 Jam Codes
No. Location Related SC Code
101 Entrance Sensor
102 Proof Tray Exit Sensor
103 Exit Sensor
104 Staple Entrance Sensor
105 Exit Sensor after jogging
106 Stapler Unit 1
109 Shift Motor SC733
110 Jogger Fence Motor SC722
111 Shift Roller or Guide Plate Motor SC732, SC736
112 Stapler Movement or Stapler Rotation Motor SC727, SC730
113 Stapler Unit 2 SC724
115 Feed Out Belt Motor SC725
116 Punch Hole Motor SC729
Finisher B468/B674 Jam Codes
No. Location Related SC Code
121 Entrance Sensor
122 Proof Tray Exit Sensor
123 Exit Sensor
124 Staple Entrance Sensor
125 Exit Sensor after jogging
126 Stapler Unit 1
127 Saddle Stitch Stapler Unit
128 Saddle Stitch Stapler Unit
129 Shift Motor SC733, SC726
130 Jogger Fence Motor SC722
131 Shift Roller or Guide Plate Motor SC732, SC736
132 Stapler Movement or Stapler Rotation Motor SC727, SC730
133 Stapler Unit 2 SC724, SC728, SC740,
SC741
134 Folder Plate Motor SC739
135 Feed Out Belt Motor SC725
136 Punch Hole Motor SC729
