ADF
15 February 2006
3-146
3.13.8
ORIGINA
L LENGT
H SENSORS
[A]:
Open the origi
nal tray.
[B]:
Lower cov
er (
x 4)
[C]:
Original
length sensor 1 – B5 (
x 1)
[D]:
Original
length sensor 2 – A4 (
x 1)
[E]:
Origi
nal length sensor 3 – LG (
x 1)
B140R876.WMF
[A]
[B]
[C]
[D]
[E]
