Service
Tables
5.9 DIP SWITCH TABLES
5.9.1 BCU (BASE ENGINE CONTROL UNIT)
BCU Base Board DIP SW101
No. Function Default Comments
1 MT-C2a CPM OFF OFF: 51cpm, ON: 50cpm
Note: This switch is for the France model only.
2
D
D
F
F
U
U
OFF
3
D
D
F
F
U
U
OFF
4 Not used OFF
5 Not used OFF
6 Region Selection - Japan: 6, 7, 8/ OFF, OFF, OFF
7 Region Selection - NA (115V): 6, 7, 8/ ON, OFF, OFF
8 Region Selection - EU (220/240V): 6, 7, 8/ OFF, ON, OFF
D
D
F
F
U
U: Design, Factory Use only. Do not change these settings.
5.9.2 CONTROLLER BOARD
Controller Board DIP SW 4
No. Function Default Comments
1 Not used OFF
2 Boot mode ON ON: Quick Boot, OFF: Normal Boot
Note: The boot time is longer when this switch
is OFF because the machine performs a full
system check.
3 Not Used OFF
4 Not Used OFF
5 Boot Selection OFF Flash ROM Boot: 5, 6, 7/ OFF, OFF, OFF
6 Boot Selection OFF SD Card 1 Boot: 5, 6, 7/ OFF, ON, OFF
7 Boot Selection OFF SD Card 2 Boot: 5, 6, 7/ ON, ON, OFF
SD Card 3 Boot: 5, 6, 7/ OFF, OFF, ON
8 Not Used OFF
Controller Board DIP SW 5
No. Function Default Comments
1
D
D
F
F
U
U
OFF
2 Not Used OFF
D
D
F
F
U
U: Design, Factory Use only. Do not change these settings.
Controller Board DIP SW 6
No. Function Default Comments
1 Not Used OFF
2 Not Used OFF
3 Not Used OFF
4 Not Used OFF
