SPECIFICATIONS 15 February 2006
Spec-6
3. OPTIONAL EQUIPMENT
3.1 A3/DLT KIT (B475)
Paper Size
A3, B4, 11" x 17", 8
1/2" x 14", A4 SEF, A4 LEF, 81/2" x 11"
SEF, 11" x 8
1/2" LEF
Paper Weight
52 ~ 163 g/m
2
16 ~ 40 lb. Bond
50 ~ 60 lb. Cover
90 lb. Index (no Tab)
Tray Capacity
1,000 sheets (80 g/m
2
, 20lb)
3.2 LCT (LARGE CAPACITY TRAY) (B473)
Paper capacity 4,000 sheets3
Paper Sizes A4 LEF, B5 LEF, 81/2" x 11" LEF
*1
Paper Weight
52 ~ 128 g/m
2
(14 ~ 34 lb)
Pick-up and Feed FRR (Feed and Reverse Roller)
Power Consumption Less than 50 W (Max.)
Power Supply DC24 V, 5V (powered by the main unit)
Rated Voltage of Output
Connector
Max. DC 24 V
Dimensions (W x D x H) 314 x 458 x 659 mm (12.4" x 18.1" x 25.9")
Weight 20.0 kg (44 lb.)
*1
: In platen mode, APS (Auto Paper Select) with the original length and original width sensors
are not used.
