15 February 2006
DEVELOPMENT AND TONER SUPPLY
6-73
Detailed
Descriptions
6.9.9
TONER BOTTLE SUPPLY
AND VENTILATION
The toner s
upply moto
r [A] (a dc motor)
and gears [B] r
otate the ton
er bottle [C].
The toner c
ooling
f
an [D] (
below the oper
ation panel
) ventilates
the area ar
ound the
bottle.
Th
is fan
always
switches off a
nd on with th
e polygonal
mirror motor
.
B246D932.
W
MF
B246D933.
W
MF
[D]
[A]
[B]
[C]
