OPERATION PANEL AND EXTERNAL COVERS 15 February 2006
3-8
3.3.4 LEFT COVERS
[A]: Left upper cover ( x 2)
• Slide down to remove.
• When re-attaching, before tightening the screws make sure that 1) the tabs
on the cover are engaged with the grooves on the machine, and 2) the
catches on the cover are engaged with the shoulder screws.
[B]: Left lower cover ( x 2)
• Slide down to remove.
• When re-attaching, before tightening the screws make sure that the tabs on
the cover are engaged with the grooves on the machine.
B246R904.WMF
[A]
[B]
