FUSING UNIT 15 February 2006
3-64
3.9.4 FUSING UNIT THERMISTORS AND THERMOSTATS
Fusing unit (☛ 3.9.1)
[A]: Upper cover ( x 1)
[B]: Press in to release the pawls inside, then remove.
Important: Make sure that the pawls [B] engage correctly when you install
the unit again.
B246R989.WMF
[A]
[B]
