Z-FOLDING UNIT (B660) 15 February 2006
1-66
1.13 Z-FOLDING UNIT (B660)
1.13.1 ACCESSORY CHECK
Check the accessories and their quantities against this list:
Description Q’ty
1. Lock Bracket – Rear (Cover Interposer Tray) .................... 1
2. Lock Bracket – Rear ......................................................... 1
3. Lock Bracket – Front (Cover Interposer Tray)*1 ................ 1
4. Lock Bracket – Front*1 ...................................................... 1
5. Ground Plate (Cover Interposer Tray) .............................. 1
6. Ground Plate (Z-folding unit) ............................................ 1
7. Ground Plate (Finisher or Cover Interposer Tray) ............ 1
8. Right Docking Bracket ....................................................... 1
9. Left Docking Bracket ......................................................... 1
10. Front Spacer *2 ................................................................. 1
11. Rear Spacer *2.................................................................. 1
12. Power Cord........................................................................ 1
13. Sponge Strip...................................................................... 1
14. Screws M3 x 6 ................................................................... 8
15. Screws M4 x 6 ................................................................... 8
*
1
Items 3, 4, are not required for the B706 (SR841) with B070/B071.
*
2
Items 10, 11 are not required for the B674 (SR861)
B660I003.WMF
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
