SCANNER
15 February 2006
3-20
3.4.10
SCA
NNER WIRE REPLACEMENT
Preparation for Rem
oval
ADF and top covers
(
☛
3.4.1)
Operation panel (
x 1
) (
☛
3.3.1)
[A]:
Scanner unit ex
ternal cover (
x 4,
x 1)
[B]:
Left stay (
x 5)
[C]:
Right stay (
x 5)
[D]:
ADF upper support frame (
x 8)
[E]:
Lower
support frame (
x 6)
[F]:
Scanner unit front panel (
x 6)
B246R920.WMF
B246R921.WMF
[A]
[B]
[C]
[D]
[E]
[F]
248
250
