15 February 2006
ADF
3-143
Replacement
Adjustm
ent
3.13.5 REGISTRA
TION
SENSOR
Open the feed cover.
Feed unit (
☛
3.11.8)
[A]:
Guide plate (
x 3)
[B]:
Registr
ation sensor bracket (
x 1)
[C]:
Registration sensor
(
x 1
)
B140R871.WMF
B140R872.WMF
[A]
[B]
[C]
371
373
