15 February 2006 INPUT/OUTPUT CHECK
5-205
Service
Tables
5.6.10 FINISHER 2 OUTPUT CHECK: 6125
6125 Finisher Output Check: Finisher 2
These are the input checks for the 3000-Sheet Finisher B706.
001 Job Cancel 014 Staple Lift Motor
002 Main Motor 015 Staple Exit Motor
003 Shift Tray Exit Motor 016 Exit Motor
004 Proof Junction Gate Solenoid 017 Hold (Fold Plate) Motor
005 Shift Relay Motor 018 Pre-Stack Solenoid
006 Jogger Motor 019 Guide (Junction Gate) Solenoid
007 Stapler Main Motor 020 Staple Release Solenoid
008 Stapler Motor 021 Front Hold (Fold) Motor
009 Punch Motor 022 Rear Hold Motor
010 Stapler Solenoid 023 Reverse Drive Motor
011 Knock (Staple Hammer) Motor 024 Reverse Feed Motor
012 Stack Feed Out Motor 025 Exit Jogger Motor
013 Shift Motor 026 Exit Jogger Release Motor
