Hop Hostname/Last Ingress MAC/name Egress MAC/Name Relay
--- ------------------------ ---------------------- ---------------------- -----
1 abc 0001.0203.0401 [Ok] FDB
0000-0001.0203.0400 Not present
2 bob 0001.0203.0402 [Ok] MPDB
abc Gi0/1/0/2.3
3 cba 0001.0203.0403 [Ok] Hit
bob Gi0/2/0/3.45
Replies dropped: 0
Traceroute at 2009-05-18 12:15:47 to 0001.0203.0409,
TTL 64, Trans ID 3, automatic:
00:00:05 remaining
Traceroute at 2009-05-18 12:20:10 explore to ffff.ffff.ffff,
TTL 64, Trans ID 4, Timeout auto, Reply Filter Default:
Hop Hostname/Last Ingr/Egr MAC/name Relay
----------------- ------------------------ -------- ---------------------- -----
1 abc Ingress 0015.0000.323f [Ok] FDB
0000-0001.0203.0400 Gi0/0/0/0.1
2 abc Egress 0015.0000.323e [Ok] FDB
abc Te0/1/0/0.1
3 0002-0016.eeee.1234 Ingress 0016.eeee.1234 [Ok] FDB
abc Te0/4.23
4 0000-0016.eeee.4321 Egress 0016.eeee.4321 [Ok] FDB
0002-0016.eeee.1234 Gi1/2.23
5 rtr Ingress 0015.0000.f123 [Ok] FDB
0002-00.16.eeee.4321 Gi0/0/0/0
2 abc Egress 0015.0000.323d [Ok] FDB
abc Te0/1/0/1.1
3 pe2 Ingress 0017.0000.cf01 [Ok] FDB
abc Te0/0/2/0/1.450
4 pe2 Egress 0017.0000.cf01 [Ok] Drop
pe2 Gi0/0/0/0.451
4 pe2 Egress 0017.0000.cf01 [Ok] FDB
pe2 Gi0/0/0/1.452
5 ce2 Ingress 0015.0000.8830 [Ok] FDB
pe2 Gi0/1/0/0
Replies dropped: 0
Table 17: show ethernet cfm traceroute-cache Field Descriptions
DescriptionField
Date and time the traceroute was started.Traceroute at
Destination MAC address.to
(Exploratory traceroutes) MAC address of the target
for the exploratory traceroute.
explore to
Initial Time To Live used for the traceroute operation.TTL
Transaction IDTrans ID
(Exploratory traceroutes) If no timeout was
configured, “Timeout auto” is shown.
Timeout
(Exploratory traceroutes) Type of filter.Reply Filter
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
350
Ethernet OAM Commands on the Cisco ASR 9000 Series Router
show ethernet cfm traceroute-cache
