DescriptionField
Indicates whether the tunable dispersion compensator
(TDC) is in the acquiring state or locked state. The
status is invalid if there is a major alarm.
Status
Indicates a value between –700 and +700 packets per
second (pps). The dispersion setting is read from the
optics module after the tunable dispersion
compensator (TDC) has locked.
Dispersion Setting
Not used.Reroute Control
Not used.Reroute BER
See Table 3: show controllers dwdm optics Command Output Field Descriptions, on page 60 for a description
of the optics fields.
The following example shows the output from the show controllers dwdm command with the optics keyword:
RP/0/RSP0/CPU0:router# show controllers dwdm 0/2/0/0 optics
Mon Jul 12 21:04:29.254 UTC
Optics Status
Optics Type: 10GBASE-ZR,
Wavelength Info: C-Band, MSA ITU Channel= N/A, Frequency=192THz, Wavelength=1558nm
TX Power = 1.50 dBm
RX Power = -11.86 dBm
This table describes selected fields from the show controllers dwdm command output with the optics keyword.
Table 3: show controllers dwdm optics Command Output Field Descriptions
DescriptionField
Indicates the optics type: GE or OC-768c/STM-256c
DWDM.
Optics Type
Indicates whether the clock is internal or line.Clock Source
Indicates the wavelength band: C-band or L-band.Wavelength Band
Multi Source Agreement (MSA) ITU channel number.MSA ITU Channel
Frequency of the channel in terahertz.Frequency
Wavelength corresponding to the channel number in
nanometers.
Wavelength
Value of the transmit power level.TX power
Actual optical power at the RX port.RX Power
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
60
Dense Wavelength Division Multiplexing Commands on the Cisco ASR 9000 Series Router
show controller dwdm
