Task ID
OperationsTask ID
readfr
Examples
The following example shows the output from the show frame-relay lmi command:
RP/0/RSP0/CPU0:router# show frame-relay lmi
LMI Statistics for interface POS0/1/0/0/ (Frame Relay DCE) LMI TYPE = ANSI
Invalid Unnumbered Info 0 Invalid Prot Disc 0
Invalid Dummy Call Ref 0 Invalid Msg Type 0
Invalid Status Message 0 Invalid Lock Shift 9
Invalid Information ID 0 Invalid Report IE Len 0
Invalid Report Request 0 Invalid Keep IE Len 0
Num Status Enq. Rcvd 9444 Num Status Msgs Sent 9444
Num Full Status Sent 1578 Num St Enq. Timeouts 41
Num Link Timeouts 7
LMI Statistics for interface POS0/1/0/1/ (Frame Relay DCE) LMI TYPE = CISCO
Invalid Unnumbered Info 0 Invalid Prot Disc 0
Invalid Dummy Call Ref 0 Invalid Msg Type 0
Invalid Status Message 0 Invalid Lock Shift 0
Invalid Information ID 0 Invalid Report IE Len 0
Invalid Report Request 0 Invalid Keep IE Len 0
Num Status Enq. Rcvd 9481 Num Status Msgs Sent 9481
Num Full Status Sent 1588 Num St Enq. Timeouts 16
Num Link Timeouts 4
Table 23: show frame-relay lmi Field Descriptions
DescriptionField
Signaling or LMI specification: CISCO, ANSI, or
CCITT.
CCITT is LMI as defined by ITU-T Q.933
(02/2003) Annex A.
Note
LMI Statistics
Number of received LMI messages with invalid
unnumbered information field.
Invalid Unnumbered Info
Number of received LMI messages with invalid
dummy calls.
Invalid Dummy Call
Number of received LMI messages with invalid status
message.
Invalid Status Message
Number of received LMI messages with invalid
information identifier.
Invalid Information ID
Number of received LMI messages with invalid report
request.
Invalid Report Request
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
463
Frame Relay Commands on the Cisco ASR 9000 Series Router
show frame-relay lmi
