Layer 3 Routing Commands 1595
Command Mode
User Exec, Privileged Exec mode, Global Configuration mode and all
Configuration submodes
User Guidelines
The following fields are displayed:
Example
console#show ip pim rp-hash 239.1.2.0
RP-Address 192.168.10.1 Type Static
If no RP Group mapping exists on the router, the following message is
displayed:
No RP-Group mappings exist/learned for the specified group address.
show ip pim rp mapping
The show ip pim rp mapping command is used in User Exec and Privileged
Exec modes to display the mappings for the PIM group to the active
rendezvous points.
Syntax
show ip pim rp mapping [rp-address |candidate|static]
rp-address — An RP address.
Default configuration
There is no default configuration for this command.
Command Mode
User Exec, Privileged Exec modes, Global Configuration mode and all
Configuration submodes
Field Description
RP Address Address of the RP
Type Origin from where this group mapping was learned.
