Layer 2 Switching Commands 425
ethernet cfm domain
Use the ethernet cfm domain command in Global Configuration mode to
enter into Maintenance Domain Configuration mode for an existing domain.
Use the optional level parameter to create a domain and enter into
maintenance domain Configuration mode. In maintenance domain
Configuration mode, maintenance associations are created and per-
maintenance domain services can be configured. Use the no form of the
command to delete a maintenance domain.
Syntax
ethernet cfm domain domain-name [level 0-7]
• domain-name—Name of the maintenance domain. Alphanumeric string
of up to 43 characters.
Default Configuration
No CFM domains are preconfigured.
Command Mode
Global Configuration mode
User Guidelines
Each domain must have a unique name and level, for example, one cannot
create a domain qwerty at level 2 if domain qwerty already exists at level 1.
Likewise, one cannot create a domain dvorak at level 2 if a domain of any
name exists at level 2.
Example
In this example, a domain “vin” is created at level 1.
console(config)#ethernet cfm domain vin level 1
ethernet cfm mep active show ethernet cfm maintenance-points
remote
ethernet cfm mep archive-hold-time show ethernet cfm statistics
ethernet cfm mip level
–
