Smartrise C4 User Manual

C4 User Manual
Page 70 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
The table below lists the Debug and About menu structures.
Table 26: Debug and About Menu Structures
Menu
Description
MAIN MENU
Debug
Debug menu options
About
View job name and software version
Debug
Enter Car Calls
Manually latch car calls. Calls entered here bypass
security.
Enter Hall Calls
Enter hall calls to a specific landing and mask
Enter Door Command
Enter door commands
Edit Parameters
Edit parameters in hex or decimal
View Network Packet
Debug option to view network packets
View Group packets
Debug option to view group packets
View Debug Data
Debug option to view various controller data
Acceptance Test
Acceptance testing options
EmergencyBitmap
Emergency power debug option
Module Statuses
Debug option to view module status
Drive Setup
Drive setup options
Car Data
View car data
Car Destination
View car destination data
Run Counter
View number of runs car completed
DebugRuns
Random run generator
XReg Destination
Cross registration destination data
XReg Data
Miscellaneous cross registration data
SH Dynamic Parking
Parking based on priority landings
SH Predict Parking
Parking assignment based on prior history
SH Remote Commands
Virtual commands to the controller
View Module Data
View various information associated to specific modules
Enter Car Calls
Front
Generate front car calls
Rear
Generate rear car calls
Edit Parameters
Hex Format
Edit parameters in Hex format
Decimal Format
Edit parameters in Decimal format
Module Statuses
Motion Status
Motion sequence status
Pattern Data
View status of pattern
Auto Status
View status of auto operation
Recall Status
View status of car recall operation
Fire Status
View status of fire service operation
