C4 User Manual
Page 90 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
5. From the BPS TIMEOUT menu, enter the maximum time the BPS can remain open or
closed before a fault occurs. Go to step 8.
Figure 111: BPS TIMEOUT Menu
6. From the SECONDARY BRAKE SETUP menu, scroll and select BPS – Stuck Inactive.
Figure 112: SECONDARY BRAKE SETUP Menu – BPS2 TIMEOUT Menu
7. From the BPS TIMEOUT menu, enter the maximum time the BPS can remain open or
closed before a fault occurs. See Figure 111.
8. Scroll right and press Save.
6.13 Disable Latching Faults
When enabled, the primary and secondary brake faults are not latching. When set to disabled
and a fault occurs, a fault will be displayed. To reset the fault, the user must reset the MR
board.
The following procedure describes how to enable the controller to latch faults.
1. Navigate to MAIN MENU | SETUP | BRAKE SETUP. See Figure 56.
2. From the BRAKE SETUP menu, scroll and select Disable Latching Faults.
Figure 113: BRAKE SETUP Menu – Disable Latching Faults
To Next Page
