Table 49: Description of Emergency Power Outputs
Output
Description
Lamp On EP
Car is on emergency power operation.
Select 1
Car is on emergency power operation and is recalling
or has been released back into automatic operation.
Select 2
Car is on emergency power operation and is recalling
or has been released back into automatic operation.
Select 3
Car is on emergency power operation and is recalling
or has been released back into automatic operation.
Select 4
Car is on emergency power operation and is recalling
or has been released back into automatic operation.
Select 5
Car is on emergency power operation and is recalling
or has been released back into automatic operation.
Select 6
Car is on emergency power operation and is recalling
or has been released back into automatic operation.
Select 7
Car is on emergency power operation and is recalling
or has been released back into automatic operation.
Select 8
Car is on emergency power operation and is recalling
or has been released back into automatic operation.
Table 50: Description of Fire/Earthquake Outputs
Output
Description
EQ Slow Lamp
Activates when the car is in EQ Hoistway Scan
operation.
Fire I Active
Used by Peelle door operator. Active if Fire Phase 1 is
active and recall has not completed.
Fire I Hold
Activates when the car has arrived at the fire recall
floor and is on Fire Phase 1.
Fire II Active
Used by Peelle door operator. Active if Fire Phase 2 is
active.
Fire II Hold
Used by Peelle door operator. Active if on Fire Phase 2
hold operation.
Fire Shunt
Activates when the car is on fire service and has
completed its recall.
Lamp EQ
Turns on when the car is on seismic or counterweight
derail modes of operation.
Lamp Fire
Activates when the car is in fire service operation.
Depending on the configuration, it will either flash
every 500 ms or stay ON the whole time.
Lamp Fire Lobby
Activates when the car is in fire service operation.
Depending on the configuration it will either flash
every 500 ms or stay ON the whole time.
Lamp Seismic Status
Activates when the car is on Seismic.
