18.3 Enable Hall Security
When hall security is enabled, access to designated floors are restricted to authorized users.
The following procedure describes how to enable hall security.
1. Navigate to MAIN MENU | SETUP | MISCELLANEOUS. See Figure 58.
2. From the MISCELLANEOUS menu, scroll and select Enable Hall Security.
Figure 371: MISCELLANEOUS Menu – Enable Hall Security
3. From the ENABLE HALL SECURITY menu, scroll and select On to enable hall security.
Figure 372: ENABLE HALL SECURITY Menu
4. Scroll right and press Save.
18.4 Hall Security Mask
The hall security mask marks what hall call masks require hall security contacts. Each bit
corresponds to a different Hall board function ID. This mask is separated between front and
rear masks (HSMF and HSMR) by the Hall Rear Door Mask (see section 18.10 Hall Rear Door
Mask. The hall security mask parameter is 08-0208. For the list of parameters, see the C4
Parameter List.
The following procedure describes how to set Hall Security Mask.
1. Navigate to MAIN MENU | SETUP | GROUP SETUP. See Figure 60.
2. From the GROUP SETUP menu, scroll and select Hall Security Mask.
Figure 373: GROUP SETUP Menu – Hall Security Mask
