Signal to blaine valve controller that the car is
attempting an inspection run.
Triggers the leveling speed valve in the down direction.
Triggers the leveling speed valve in the up direction.
Triggers the low speed valve in the down direction.
Triggers the low speed valve in the up direction.
Triggers the medium speed valve in the down direction.
Triggers the medium speed valve in the up direction.
Table 47: Description of Front Doors Outputs
Arrival down turns on when the car arrives at a floor
then opens its doors and intends to continue moving
down.
Arrival up turns on when the car arrives at a floor then
opens its doors and intends to continue moving up.
Retiring CAM. For swing hall doors and some freight
doors, this output controls the hall locks. This output
turns on when the car is in motion.
Door closed limit status. This output turns ON when
the door closed limit switch signals the door is closed.
Used by Peelle door operator. Triggers door operator
fast open/close where landing and car door movement
will occur simultaneously.
Door open limit status. This output turns ON when the
door open limit switch signals the door is open.
Door nudge. After a specified timeout, if the door has
not closed, the doors will move to a nudging state
where the PHE is ignored and the nudging output will
turn on.
Safety edge broken status. This output turns ON when
the safety edge or photoeye is broken.
Used by Peelle light curtain to test for photoeye failure
prior to each close attempt.
Used by Peelle door operator. Activates 5 seconds
before starting door close and remains on until doors
fully closed.
