The table below lists the Setup – Setup I/O, Safety, and Run Timers menu structures.
Table 17: Setup – Setup I/O, Safety, and Run Timers Menu Structures
Menu
Description
MAIN MENU
Setup
Allows the user to setup the elevator configuration
Setup
Setup I/O
Configure inputs and outputs
Safety
Allows the user to adjust safety related functions
Run Timers
Adjust start sequence and stop sequence timers
Setup I/O
Invert Inputs
Invert selected inputs
Invert Outputs
Invert selected outputs
Setup Inputs
Assign inputs
Setup Outputs
Assign outputs
Invert Inputs
Machine Room
Change state of input to the MR board
Car Top
Change state of input to the CT board
Car Operating Panel
Change state of input to the COP board
Riser
Change state of input to the Riser board
Expansion 1-8
Change state of input to the Expansion 1-8 boards
Expansion 9-16
Change state of input to the Expansion 9-16 boards
Expansion 17-24
Change state of input to the Expansion 17-24 boards
Expansion 25-32
Change state of input to the Expansion 25-32 boards
Expansion 33-40
Change state of input to the Expansion 33-40 boards
Invert Outputs
Machine Room
Change state of output to the MR board
Car Top
Change state of output to the CT board
Car Operating Panel
Change state of output to the COP board
Riser
Change state of output to the Riser board
Expansion 1-8
Change state of output to the Expansion 1-8 boards
Expansion 9-16
Change state of output to the Expansion 9-16 boards
Expansion 17-24
Change state of output to the Expansion 17-24 boards
Expansion 25-32
Change state of output to the Expansion 25-32 boards
Expansion 33-40
Change state of output to the Expansion 33-40 boards
Setup Inputs
Machine Room
Assign inputs to the MR board
Car Top
Assign inputs to the CT board
Car Operating Panel
Assign inputs to the COP board
Riser
Assign inputs to the Riser board
Expansion 1-8
Assign inputs to the Expansion 1-8 boards
Expansion 9-16
Assign inputs to the Expansion 9-16 boards
