3. From the QUICK STOP DECELERATION menu, enter the rate of deceleration for a quick
stop.
Figure 143: QUICK STOP DECEL Menu
4. Scroll right and press Save.
9.3 Leveling Deceleration
Leveling Deceleration is the rate of deceleration from leveling speed to 0. This value should not
need to be changed from the maximum set value. A value too low may cause inconsistent floor
counts.
The adjustment range is from 0 -25.5 fps
2
.
• Default = 25.5 fps
2
• Units of measure = fps
2
The following procedures describe how to set leveling deceleration.
1. Navigate to MAIN MENU | SETUP | S-CURVE. See Figure 55.
2. From the S-CURVE menu, scroll and select Leveling Decel.
Figure 144: S-CURVE Menu – Leveling Decel
3. From the LEVELING DECELERATION menu, enter the rate of deceleration for leveling.
Figure 145: LEVELING DECEL Menu
4. Scroll right and press Save.
