The table below lists the Status – Inputs, Outputs, and Expansion Status menu structures.
Table 14: Status – Inputs, Outputs, and Expansion Status Menu Structures
Displays information about the current state of the controller
Shows the status of all programmed inputs to the MR board
Shows the status of all programmed outputs from the MR board
Shows the status of Brake board
Shows the status of the secondary Brake board
Shows communication status for a group of Expansion boards
Shows the status of the Riser board
Shows communication status for all Hall boards
Shows communication status for all Hall Lantern boards
Shows communication status for all Hall Security boards
Shows the status of inspection related inputs
Shows the status of all locks
Shows the status of all hoistway accesses
Shows the status of safety inputs
Shows the status of all active relays
Shows the status of all door operator signals
Shows the status of all contactor monitoring signals
Shows the status inputs under auto operation category
Shows the status of fire/earthquake inputs
Shows the status E-Power inputs
Shows the status of various other inputs
Shows the outputs that are in auto operation
Shows the status of front door outputs
Shows the status of rear door outputs
Shows the status of fire/earthquake outputs
Shows the status of E-Power outputs
Shows the status of inspection outputs
Shows the status of control outputs
Shows the status of safety outputs
Shows the status of front car call lamps
Shows the status of rear car call lamps
Shows the communication status for Expansion group 1
Shows the communication status for Expansion group 2
